ABOUT US
SERVICE POLICY
Gala Stage additions to bringing innovative concepts to the international marketplace and it also adopted this principle and supports all the work it has done and will do with technical solutions.
PROJECT MANAGEMENT
Gala Stage Mechanical Systems has been taken part in many projects particularly in Turkey and as well as aborad in the World
QUALITY
High-Level technical office equipped and best trained staff of engineers, TUV and world standarts with high safety technology, integrated system solutions for mechanical and electrical equipment, silent operation and more.
SERVICE MAINTENANCE
Gala Stage Mechanical Systems sends you the tests, trainings and necessary documentation of every system that has been installed and put in use. Even if the system has completed the “Warranty” period, our service team enters the “Lifetime Warranty” tracking system and the 24/7 assistance process is carried out to ensure that the systems operate smoothly.
OUR PRODUCTS
ACOUSTIC WOOD PANEL
Acoustic Wood Panels applied on,
The ceiling and walls in large volume buildings which provide excellent acoustical absorption in the halls with perforated and scratchy perforation options.
Product Code: G0L0
Ceiling: 600x600 mm Wall: 600x1200 mm Thickness: 8, 12, 18 mm - MDF LAM Front and Rear Surface: Flat
Product Code: G1L0
Ceiling: 600x600 mm Wall: 600x1200 mm Thickness: 8, 12, 18 mm - MDF LAM Front Surface: Perforated, distance between holes 32x32 mm, average 1000 holes / m², hole diameter 8 mm Rear Surface: 2 mm Acoustic Fabric coated
Product Code: G2L0
Ceiling: 600x600 mm Wall: 600x1200 mm Thickness: 8, 12, 18 mm - MDF LAM Front Surface: Perforated, distance between holes 32x16 mm, average 2000 holes / m², hole diameter 8 mm Rear Surface: 2 mm Acoustic Fabric coated
Product Code: G3L0
Ceiling: 600x600 mm Wall: 600x1200 mm Thickness: 8, 12, 18 mm - MDF LAM Front Surface: Perforated, distance between holes 16x16 mm, average 4000 holes / m², hole diameter 8 mm Rear Surface: 2 mm Acoustic Fabric coated
Product Code: G4L0
Ceiling: 600x600 mm Wall: 600x1200 mm Thickness: 8, 12, 18 mm - MDF LAM Front Surface: Perforated, distance between holes 16x8 mm, average 8000 holes / m², hole diameter 8 mm Rear Surface: 2 mm Acoustic Fabric coated
Product Code: G0L1
Ceiling: 600x600 mm Wall: 600x1200 mm Thickness: 12, 18 mm - MDF LAM Front Surface: Striped, distance between lines 32 mm, line depth 6 mm, line width 4 mm, average line 32 mt / m²
Product Code: G0L2
Ceiling: 600x600 mm Wall: 600x1200 mm Thickness: 12, 18 mm - MDF LAM Front Surface: Striped, distance between lines 16 mm, line depth 6 mm, line width 4 mm, average line 64 mt / m²
Product Code: G0L3
Ceiling: 600x600 mm Wall: 600x1200 mm Thickness: 12, 18 mm - MDF LAM Front Surface: Striped, distance between lines 8 mm, line depth 6 mm, line width 4 mm, average line 124 mt / m²
Product Code: G0L4
Ceiling: 600x600 mm Wall: 600x1200 mm Thickness: 12, 18 mm - MDF LAM Front Surface: Striped, distance between lines 4 mm, line depth 6 mm, line width 4 mm, average line 248 mt / m²
Product Code: G1L1
Thickness: 12, 18 mm - MDF LAM Front Surface: Striped, distance between lines 32 mm, line depth 6 mm, line width 4 mm, average line 32 mt / m² Rear Surface: Perforated, spacing between holes 32x32 mm, average 1000 holes / m², hole diameter 8 mm, 2 mm Acoustic Fabric coated
Product Code: G2L1
Thickness: 12, 18 mm - MDF LAM Front Surface: Striped, distance between lines 32 mm, line depth 6 mm, line width 4 mm, average line 32 mt / m² Rear Surface: Perforated, distance between holes 32x16 mm, average 2000 holes / m², hole diameter 8 mm, 2 mm Acoustic fabric covered
Product Code: G2L2
Thickness: 12, 18 mm - MDF LAM Front Surface: Striped, distance between lines 16 mm, line depth 6 mm, line width 4 mm, average line 62 mt / m² Rear Surface: Perforated, distance between holes 32x16 mm, average 2000 holes / m², hole diameter 8 mm, 2 mm Acoustic fabric covered
Product Code: G3L2
Thickness: 12, 18 mm - MDF LAM Front Surface: Striped, distance between lines 16 mm, line depth 6 mm, line width 4 mm, average line 62 mt / m² Rear Surface: Perforated, distance between holes 16x16 mm, average 4000 holes / m², hole diameter 8 mm, 2 mm Acoustic Fabric coated
Product Code: G4L3
Thickness: 12, 18 mm - MDF LAM Front Surface: Striped, distance between lines 16 mm, line depth 6 mm, line width 4 mm, average line 124 mt / m² Rear: perforated, distance between holes 16x8 mm, average 8000 holes / m², hole diameter 8 mm, 2 mm Acoustic fabric covered
ACOUSTIC CLOTH PANEL
Fabric Panels,
Usually applied in cinema halls, are obtained by coating high density rock wool with acoustic fabric.
ACOUSTIC DOOR
Acoustic Doors are designed
To reduce the escape of noise and sound waves from conference hall to outside.
CONFERENCE CHAIR
The Comfort of the
Audience is ensured by the options of the seat mechanic and the writing table in the conference rooms, also the sprawl back and the cupboard models in the cinema as well as the specific project designs.
TV & STUDIO APPLICATION
Interior Design Profects of
News, Sports, Food, Contest and Show programs are prepared and studio designs are applied.
OUR REFERENCES
Free Discovery
You can get a free quote for our stage acoustic services by filling out the form on the right.
